Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Features of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Universal Temperature Converter KFD2-UT2-Ex1

1-channel isolated barrier

24 V DC supply (Power Rail)

Thermocouple, RTD, potentiometer or voltage input

Current output 0/4 mA ... 20 mA

Sink or source mode

Configurable by PACTware

Line fault (LFD) and sensor burnout detection

Up to SIL 2 acc. to IEC 61508/IEC 61511

Technical Specification of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Product Description of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Current output 0/4 mA ... 20 mA

General specifications of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Signal type Analog input

Functional safety related parameters of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Safety Integrity Level (SIL) SIL 2

Supply of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Connection terminals 14+, 15- or power feed module/Power Rail

Rated voltage 20 ... 30 V DC

Ripple within the supply tolerance

Power dissipation/power consumption ≤ 0.98 W / 0.98 W

Interface of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Programming interface programming socket

Input of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Connection side field side

Connection terminals 1, 2, 3, 4

RTD type Pt10, Pt50, Pt100, Pt500, Pt1000 (EN 60751: 1995)

type Pt10GOST, Pt50GOST, Pt100GOST, Pt500GOST, Pt1000GOST (6651-94)

type Cu10, Cu50, Cu100 (P50353-92)

type Ni100 (DIN 43760)

Measuring current approx. 200 µA with RTD

Types of measuring 2-, 3-, 4-wire connection

Lead resistance max. 50 Ω per line

Measurement loop monitoring sensor breakage, sensor short-circuit

Thermocouples type B, E, J, K, N, R, S, T (IEC 584-1: 1995)

type L (DIN 43710: 1985)

type TXK, TXKH, TXA (P8.585-2001)

Cold junction compensation external and internal

Measurement loop monitoring sensor breakage

Potentiometer 0 ... 20 kΩ (2-wire connection), 0.8 ... 20 kΩ (3-wire connection)

Voltage selectable within the range -100 ... 100 mV

Input resistance ≥ 1 MΩ (-100 ... 100 mV)

Output of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Connection side control side

Connection output I: terminal 7: source (-), sink (+), terminal 8: source (+), terminal 9: sink(-)

Output Analog current output

Current range 0 ... 20 mA or 4 ... 20 mA

Fault signal downscale 0 or 2 mA, upscale 21.5 mA (acc. NAMUR NE43)

Source load 0 ... 550 Ω

open-circuit voltage ≤ 18 V

Sink Voltage across terminals 5 ... 30 V. If the current is supplied from a source > 16.5 V,

series resistance of ≥ (V - 16.5)/0.0215 Ω is needed, where V is the source voltage.

The maximum value of the resistance is (V - 5)/0.0215 Ω.

Transfer characteristics of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Deviation

After calibration Pt100: ± (0.06 % of measurement value in K + 0.1 % of span + 0.1 K (4-wire connection))

thermocouple: ± (0.05 % of measurement value in °C + 0.1 % of span + 1 K (1.2 K for types R and S))

this includes ± 0.8 K error of the cold junction compensation

mV: ± (50 µV + 0.1 % of span)

potentiometer: ± (0.05 % of full scale + 0.1 % of span, (excludes errors due to lead resistance))

Influence of ambient temperature deviation of CJC included:

Pt100: ± (0.0015 % of measurement value in K + 0.006 % of span)/K ΔTamb*)

thermocouple: ± (0.02 K + 0.005 % of measurement value in °C + 0.006 % of span)/K ΔTamb*)

mV: ± (0.01 % of measurement value + 0.006 % of span)/K ΔTamb*)

potentiometer: ± 0.006 % of span/K ΔTamb*)

*) ΔTamb = ambient temperature change referenced to 23 °C (296 K)

Influence of supply voltage < 0.01 % of span

Influence of load ≤ 0.001 % of output value per 100 Ω

Reaction time worst case value (sensor breakage and/or sensor short circuit detection enabled)

mV: 1 s, thermocouples with CJC: 1.1 s, thermocouples with fixed reference temperature: 1.1 s, 3- or 4-wire RTD: 920 ms, 2-wire RTD: 800 ms, Potentiometer: 2.05 s

Galvanic isolation of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Output/supply, programming input functional insulation, rated insulation voltage 50 V AC

There is no electrical isolation between the programming input and the supply.

The programming cable provides galvanic isolation so that ground loops are avoided.

Indicators/settings of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Display elements LEDs

Configuration via PACTware

Labeling space for labeling at the front

Directive conformity of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Electromagnetic compatibility

Directive 2014/30/EU EN 61326-1:2013 (industrial locations)

Conformity of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Electromagnetic compatibility NE 21:2006

Degree of protection IEC 60529:2001

Protection against electrical shock UL 61010-1:2004

Ambient conditions of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Ambient temperature -20 ... 60 °C (-4 ... 140 °F)

Mechanical specifications of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Degree of protection IP20

Connection screw terminals

Mass approx. 130 g

Dimensions 20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) , housing type B2

Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001

Data for application in connection with hazardous areas of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

EU-type examination certificate CESI 04 ATEX 143

Marking Ex-Hexagon II (1)G [Ex ia Ga] IIC

Ex-Hexagon II (1)D [Ex ia Da] IIIC

Ex-Hexagon I (M1) [Ex ia Ma] I

Input Ex ia

Inputs terminals 1, 2, 3, 4

Voltage Uo 9 V

Current Io 22 mA

Power Po 50 mW

Analog outputs, power supply, collective error

Maximum safe voltage 250 V (Attention! This is not the rated voltage.)

Interface

Maximum safe voltage 250 V (Attention! The rated voltage is lower.), RS 232

Certificate TÜV 02 ATEX 1797 X

Marking Ex-Hexagon II 3G Ex nA II T4

Galvanic isolation

Input/Other circuits safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V

Directive conformity

Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 60079-15:2010 , EN 50303:2000

International approvals of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

UL approval

Control drawing 116-0410

CSA approval

Control drawing 116-0314 (cCSAus)

116-0347

IECEx approval

IECEx certificate IECEx TUN 07.0003

IECEx CML 16.0126X

IECEx marking [Ex ia Ga] IIC

[Ex ia Da] IIIC

[Ex ia Ma] I

Ex nA IIC T4 Gc

General information of Pepperl+Fuchs KFD2-UT2-Ex1 Universal Temperature Converters KFD2-UT2-Ex1 Safety Barriers In Stock

Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.
